CX15

Key Features

  • Professional coaxial stage monitor
  • 2-way passive version
  • 15" LF (4in) + 2,85" HF voice coil European transducers
  • Faithful dynamic response and great range
  • Connector plate on the bottom with 2x Speakon NL4®
  • Integrated Ø35mm pole mount socket
  • Rugged and durable 15mm birch plywood construction
  • Powder coated custom perforated steel grille
Interested in this Product? Contact us!

Tech Specs

Type

Coaxial stage monitor - passive

Enclosure Design

Bass reflex

Power Output (RMS)

400W / 80W (AES)
800W / 180W (Program)
1600W (Peak)

Frequency Range

80Hz - 20kHz

Nominal Impedance

8ohm

Transducer Type

12" coaxial EU transducer
LF 4in VC + HF 2.87in VC

Dispersion

80° Axisymmetrical (conical)

Crossover Frequency

1500Hz

Max. SPL (peak)

130dB @ 1m

Connector

2x Neutrik® NL4 in parallel

Construction

15mm birch plywood, textured polyurea coating

Grille

Custom perforated metal grille w/ acoustic foam

Installation / Rigging / Flying

4 rubber feet
Ø35mm pole mount socket

Dimensions (WxDxH)

610x540x360mm
24.01x21.26x14.17in

Weight

21Kg
46.3lb
