G18

Key Features

  • Reflex Loaded passive subwoofer
  • 1x 18" (4in VC) LF EU transducer
  • 2x NL4 connected in parallel
  • Optimized for high SPL output
  • Made for an impact bass
  • Recesses on the top to facilitate the stacking
  • Rugged and durable 18mm birch plywood construction
  • Powder coated custom perforated steel grille
Interested in this Product? Contact us!

Tech Specs

Type

Compact PASSIVE subwoofer

Enclosure Design

Reflex Loaded

Power Output (RMS)

1200W (AES)
4800W (Peak)

Frequency Range

27Hz-200Hz (-10dB)

Nominal Impedance

8 Ohm

Transducer Type

18" (4in VC) LF EU transducer

Crossover Frequency

30Hz Butterworth 18dB

Max. SPL (peak)

128dB @ 1m (continuous)
134dB @ 1m (peak)

Connector

2x NL4 in parallel

Construction

18mm birch plywood with polyurea coating

Grille

Custom perforated metal grille w/ acoustic foam

Installation / Rigging / Flying

4 rubber feet, 2 side handles
Ø35mm pole mount socket
Prepared for stacking

Dimensions (WxDxH)

750x710x540mm
29.53x27.95x21.26in

Weight

55Kg
121.25lb
