CST403
Key Features
- Public address installation speaker
- Superb speech intelligibility
- 4x 3" (0.75in) FR transducer
- Suitable for 100V high impedance installations
- Wide dispersion achieved
- Solid and elegant aluminum construction
- Custom perforated metal grille
- Textured powder coating finishing
- Supplied with with C-sup M support for wall mount
Interested in this Product? Contact us!
Tech Specs
| Type | Passive installation column speaker |
|
| Enclosure Design | Trapezoidal |
|
| Power Output (RMS) | 20W |
|
| Frequency Range | 100Hz - 19kHz |
|
| Nominal Impedance | 100V line transformer in |
|
| Transducer Type | 4x 3" (0.75in) FR EU transducer (rubber surround) |
|
| Dispersion | 120° x 30° (HxV) |
|
| Crossover Frequency | 2200Hz |
|
| Max. SPL (peak) | 90dB @ 1m |
|
| Connector | Euroblock terminal |
|
| Construction | Extruded aluminum profile, textured powder coating |
|
| Grille | Custom perforated metal grille, textured powder coating |
|
| Installation / Rigging / Flying | C-sup M for wall mounting (supplied) |
|
| Dimensions (WxDxH) | 80x90x390mm |
|
| Weight | 3Kg |
