TL 200D

Key Features

  • High quality PA amplifier
  • Installation PA mixer-amplifier
  • 4 Microphone inputs and 1 Line input
  • XLR 3p balanced, Euroblock inputs
  • 4-16 ohm & constant-voltage outputs (70V and 100V)
  • Bass and Teble tone controls
  • Ding-dong and Priority muting by VOX
  • Built-in electronic protection circuitry
  • Solid construction for 19” rack - 2U mounting
Interested in this Product? Contact us!

Tech Specs

Type

PA mixer-amplifier

Power Output (RMS)

200W

Frequency Range

50Hz - 14kHz

T.H.D. (20Hz - 20kHz)

< 1% @ 1kHz

Signal-to-noise ratio

> 90 dB @ 1 kHz

Zones

No

Controls

Bass and Treble, Master,
Volume for MIC and Line in

Indicators

Power on, Signal and Clip

Inputs

Microphone, XLR/F 3p
Euroblock terminals
Line in

Outputs

4Ω, 8Ω and 100V line, AUX

Connectors

Input: 6.3mm Jack, RCA line
Output: Touch-proof binding posts

Phantom Power

+48V DC

Other Features

Ding-dong, priority MIC, MIC3/LINE3 and MIC4/LINE4 switch

Protections

Short circuit, thermal overload

Operation Voltage

230V AC (factory config.), 50–60 Hz

Power Consumption

220VA

Cooling

Continuously speed fan, 80mm / 230V AC

Dimensions (WxHxD)

2RU spaces, 345mm depth (13.58in)

Weight

12Kg
26.46lb
