i6

Key Features

  • 2-way passive installation speakers
  • Elegant, refined and lightness design
  • 6" (1.26in) FR EU transducer
  • High sensitivity 1" HF Kapton driver
  • 2x NL4MP® speakon + Phoenix Contact® Euroblock terminal
  • Optional line transformer, 100V - 8ohm / 15W / 30W power taps
  • Prepared for wall/ceiling mounting, 4x M6 inserts for "U" bracket (supplied)
  • 4x M5 inserts for Wall mount support adjustable in 2 axes (optional)
  • Rugged and durable 12mm birch plywood
Interested in this Product? Contact us!

Tech Specs

Type

2-Way passive installation speaker

Enclosure Design

Bass reflex trapezoidal enclosure

Power Output (RMS)

140W (AES)
280W (Program)

Frequency Range

80Hz - 18kHz

Nominal Impedance

8Ohm

Transducer Type

6" FR (1.26in) EU transducer
1" HF (1.00in) Kapton EU transducer

Dispersion

80° conical, aluminum horn

Crossover Frequency

2500Hz

Max. SPL (peak)

116dB @ 1m

Connector

2x NL4MP® speakon
Phoenix Contact® Euroblock speaker terminal
I6T: 100V line transformer, 8ohm / 15W / 30W power taps

Construction

12mm brich plywood, black or white finishing

Grille

Custom perforated metal grille w/ acoustic foam

Installation / Rigging / Flying

4x M6 inserts for "U" bracket (supplied)
4x M5 inserts for wall mount/ceiling support, 2-axes (optional)

Dimensions (WxDxH)

210/155x300x230mm
8.27x11.81x9.06in

Weight

6.0Kg
13.22lb
